Pure
Polyester Powder Coatings |
| |
|
| HS
Code: |
3212900000 |
|
Brand Name: |
Kianco |
|
Origin: |
China |
|
Method: |
Spray |
|
Use: |
Powder Coating |
|
Level: |
Finish Coat |
|
Substrate: |
Aluminum |
|
Appearance: |
Powder |
| |
|
Introduction:
Pure polyester is mainly made of polyester resin with TGIC or
Primidcuring agent.
Features:
Good mechanical performance and flexible film Good weather ability and suitable for long time exposed outdoor products.
Users:
Structural aluminum, wall and bridge, traffic fences, gym facility, lighting fixture, air condition outdoor machine etc
Series of Product:
Standard curing and lower temperature curing product;
Standard weather ability and super high weather ability products;
TGIC or PRIMID curing type;
It could be made to various luster and color;
It could be made to various kinds of art texture products, such as
flat, lignose grain, webbing, wrinkle, sandy, hammer tone etc.
Physical Property:
Density: 1.1-1.8 g/cm3,standard curing and lower temperature curing;
Granularity distribution: Varies with different purpose. Average
particle size is 28-40um,10um-84um, powder>90% Volatility<2%.
|
Properties |
Test
standard and Method |
Test index |
| Pencil Hardness |
GB/T
6739 -1996 |
≥ H |
|
Impact strength test |
GB/T
1732 - 93 |
50 KG cm |
|
Erichsen cupping |
GB
9753-88 |
＞6mm |
| Adhesion |
GB/T
9286-1998 |
0grade |
| Bend test |
GB
6742-86 |
3mm |
| Salt
spray
test |
GB/T
1771-91 |
100h no change |
| Humid heat test |
GB/T
1740-79 |
1000h ≤
1 grade |
| Accelerated light
aging test |
GB/T
1740-1979 |
QUV 0.78m/m2 340nm 500h |
Apply Condition:
Pretreatment: Phosphate, Chromate.
Coating method:
Electrostatic-fluidized bed coating; Corona electrostatic spray
coating; Tribe-electrification coating.
Curing condition:
200°C/10min or 180°C/15min or 140°C/25min.
Packing:
Double PVC bag, net weight is 20KG each carton.
Storage:
Storage: Dry room with good ventilation, Temperature is lewder than
30°C, avoid direct sunlight. There are 12 months to maintain under
this condition. Expired products still cannot be used unless testing
results meet the utilization Stan dads.
Health and Safety:
There are no hazardous ingredients in all the raw materials of
powder coatings and no hazardous gas will be released while using.
However, the inhalation of dusts should be avoided. An operator
should wear an anti-dust mask and try best to avoid long-term
contact with the powder coating. Those coatings stacked on the skin
should be washed by soa.
|
