Rubbers
Product   >> Rubber
Kianco Rubber Pipes Product

Model: KMBPP-RBR-D1002
Name: Dredging Rubber Pipe

Features:
Product Name: Big Diameter Dredging Rubber Pipe
Delivery Medium: Used for port dock seawater silt sand discharge flood etc.
Temperature Available: From -20Degrees Celsius To 40Degrees Celsius

Advantages:
1. High quality
2. Competitive price
3. Direct marketing
4. ID152mm-1300mm

Remarks: Production is available according to customers ' requirements and drawings.
Specification:

  Inside Diameter

 Outside Diameter

Working Pressure

Burst Pressure

  Vacuum Pressure

Length
mm inch mm inch Mpa bar Mpa bar Kpa bar m

 152

 6"

 182

 7-1/4"  1.2 12  2.4 24  80 0.8

    20

 203

 8"

 233

 9-1/5"  1.2 2.4  2.4 24  80 0.8

    20

 254

 10"

 284

 11-1/5"  1 10  2 20  80 0.8

    10

 304

 12"

 340

 13-2/5"  1 10  2 20  80 0.8

   6-10

 350

 14"

 390

 15-2/5"  1 10  2 20  80 0.8

   6-10

 450

 18"

 486

 19-1/5"  0.7 7  1.5 15  80 0.8

   6-10

 550

 22"

 590

 23-3/5"  0.7 7  1.5 15  80 0.8

   6-10

 600

 24"

 640

 25-3/5"  0.7 7  1.5 15  80 0.8

   6-10

 700

 28"

 750

 29-3/5"  0.7 7  1.5 15  80 0.8

   6-10

 800

 32"

 850

 33-1/2"  0.5 5  1 10  80 0.8

   6-10

 1000

 40"

 1050

 41-1/2"  0.5 5  1 10  80 0.8

    6

 1200

 48"

 1250

 49-1/5"  0.5 5  1 10  80 0.8

    6

 1300

 52"

 1350

 53-1/5"  0.5 5  1 10  80 0.8

    6
