Features: |
|
●Light weight and compact size |
|
●100% full load burn-in test |
|
●Surge protection by using
soft start electrical design |
|
●Wide input voltage range |
|
●Short-circuit, over-load, over-voltage
protection |
|
●High reliability, high
efficiency, low operating temperature, long life |
|
|
|
A
|
B
|
C
|
D
|
|
D
Series
|
+5V，+12V
|
+5V，-24V
|
±5V，±15V
|
|
|
T
Series
|
±5V+12V
|
+5V，12V
|
+5V，±12V
|
+5V，+12V，+24V
|
|
Q
Series
|
±5V，12V
|
|
|
+5V，±12V，+24V
|
|
Note 1: 85-132/170-264V
AC select A: automatic
transfer F: full range |
|
S: selected by switch
J: selected by jumper wire X: fixed |
|
Note 2: function A: over
load (over current), short-circuit protection |
|
B: over voltage protection C: over
heat protection |
|
D: cooling
automatic by fan switch (to extend long life) E: power
monitor signal |
|
F: output
external connection with TTL signal control
|
|
G: multiple-series connection
H: series connection I: charging
protection |
|
J: output voltage remote
measurement K: output in LED display |
|
|
